TIG Welders
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
HTP® Invertig 301 AC/DC Air-Cooled Package
Includes:

♦ Invertig 301 AC/DC Power Source ♦ 26 Series Air-Cooled TIG Torch with Heavy Hitter Flex Head (350 amps)* ♦ Foot Pedal ♦ Flowmeter ♦ Gas Hose ♦ Ground Cable and Clamp Assembly* ♦ Single Phase Plug

Does Not Include:
Cart, Gas Bottle, Filler Rod, Consumables

HTP® Invertig 301 AC/DC Air-Cooled Package

Product # 601779




  • List
    $5,802.00

    • Our Price:
  • $4,499.00


    • You Save: $1,303.00 !



Financing as low as

$148/mo


Apply Now!
Product Videos:

HTP® Invertig 301 AC/DC Air-Cooled Package:

Need a little more power? Introducing the HTP® Invertig 301! This 300 amp AC/DC TIG welder runs only on single phase but has all the other characteristics of the Invertig 400. The Invertig 301 features the same large LCD as the Pro Pulse™ 300 and the Invertig 400 AC/DC and also features an updated and intuitive software system, which makes parameter selection and setup a breeze. With the Invertig 301 AC/DC, you can run the following processes: TIG (GTAW), Pulsed TIG (GTAW-P), Stick (SMAW), and Pulsed Stick (SMAW-P). This machine is made in Italy, while most of the accessories are made in the USA!

The Air Cooled Invertig 301 comes with a Heavy Hitters 350 amp FLEX head and a CK Worldwide 26 series super flex cable. Rigid and Flex Lock/Swivel Heads are not available for this package. CART NOT INCLUDED

What is the difference between the Invertig 301 and the Invertig 313… the Invertig 301 ONLY runs on single phase which allows us to bring the cost down on our 300 amp TIG welders.

Stick Features

  • Arc-Force (DIG): Helps reduce "sticking" of the electrode
  • Hot-Start: For easy arc strikes
  • DC and AC Stick Welding: AC frequency and balance can be adjusted in Stick mode as well
  • Pulse Stick Welding: Makes bridging gaps easier, welds out of position better, and reduces heat input
  • Welds all types of electrodes
  • Pipe Mode

TIG Features

  • 300 amp output on 54 amp Single-Phase Circuit
  • Asymmetric AC allows you to limit Electrode Positive or Electrode Negative amperages separately, which gives you more control over heat input on critical welds
  • AC Balance: Adjustable from 10 to 90%; allows precise control of oxide removal vs. penetration
  • AC Frequency: 20Hz to 400Hz (under 100 amps) and 20Hz to 200Hz (over 100 amps); Helps reduce or enhance heat input and focus the arc
  • This machine has High Frequency start with the option to change to Lift-Arc Start when you work around sensitive electronics where high frequency is unwanted
  • Three AC Waveforms: Soft Square, Square, and Triangular
  • Pipe Mode

*Upgrade options available for the machine package, via drop down boxes above, for additional charges.*

IMPORTANT INFORMATION REGARDING TRUCK FREIGHT SHIPMENTS

The Invertig 301 SHIPS to any business/commercial address with access to a forklift in the Contiguous United States (i.e., the lower 48) for a flat rate fee applied at check out.  If you choose to ship the machine to your residence, accessorial fees will apply (a residential delivery fee, a lift-gate service fee, and possibly a limited access fee). Accessorial fees vary by ship to location and by freight carrier. You may place your order online, but you will be contacted by Customer Service to arrange and pay for any applicable accessorial fees. To avoid additional accessorial fees, we can also ship the machine to your nearest freight terminal, where the carrier will hold your machine for you to pick-up.

Also, if your ship to address is in Alaska, Guam, Hawaii, Puerto Rico, or any other U.S. Territory outside of the Contiguous United States, additional shipping charges will apply and accessorial fees may apply. You may still place your order online, but you will be contacted by Customer Service to arrange and pay for partial shipping along with any applicable accessorial fees.



IMPORTANT INFORMATION REGARDING TRUCK FREIGHT SHIPMENTS AND LOST OR DAMAGED GOODS

KEEP ALL SHIPPING CARTONS AND PACKAGING MATERIALS!

Your truck freight shipment leaves our facility and is accepted by the freight carrier in good condition. The material becomes your property when signed for by the freight carrier. Our responsibility for the shipment ceases when signed for and removed from our facility by the freight carrier.

Inspect your shipment thoroughly as soon as received. If possible, unpack the shipment in the presence of the driver. If this is a "HOLD ON DOCK FOR PICK-UP" shipment, inspect the shipment prior to leaving the freight terminal. If you do not inspect the shipment for loss or damage prior to signing for and leaving the freight terminal with the shipment, then the freight carrier will claim that you damaged the shipment bringing it home. If you notice loss or damage, then you must note this on the freight bill.

We are willing to assist you in every possible manner in the collections of claims for loss or damage, but this willingness does not make us responsible for such collection of claims or replacement of materials.



The HTP® Invertig 301 AC/DC Air-Cooled Package Specifications:

Input Voltage230V (208 to 240V)
Welding Current Single-Phase4 to 300A
Single-Phase Rated Output40% @ 300A
230V Single-Phase Input Amps @ Rated Load54A
Welding ModesStick
TIG 2T
TIG 4T
TIG Spot
TIG Reset
Programmable Memories30
Asymmetric ArcYes
AC Frequency (Hz)20 to 400 (Up to 100A)
20 to 200 (Over 100A)
AC Balance (%)10 to 90
Pre-Flow (Seconds)0.1 to 5.0
Post-Flow (Seconds)0.1 to 99.9
Initial Amps (%)10 to 90
Final Amps (%)10 to 90
Slope Up (Seconds)0.1 to 10.0
Slope Down (Seconds)0.1 to 10.0
Spot Time (Seconds)0.1 to 10.0
Hot Start (%)0 to 50
Arc Force (%)0 to 500
Wave FormsSoft Square
Square
Triangular
EN Amperage (%)10 to 99
EP Amperage (%)10 to 99
Duty-Cycle (Single-Phase TIG)40% @ 300A
60% @ 250A
100% @ 200A
Duty-Cycle (Single-Phase Stick)35% @ 260A
60% @ 200A
100% @ 180A
Dimensions (Length x Width x Height)26-1/2" x 12-1/4" x 17-1/2"
Weight117 Lbs.
Pulse Parameters
Pulses/Second (PPS) Stick AC & DC
Pulses/Second (PPS) TIG AC
Pulses/Second (PPS) TIG DC
Peak Time (%)
Background Amps (%)
0.4 to 5.0
0.4 to 10.0
0.4 to 999.9
10 to 90
10 to 90

Downloads/Manuals

  Owner’s Manual

 Competitor Comparison

The HTP® Invertig 301 AC/DC Air-Cooled Package Accessory Packages:



The Invertig 301 Air Cooled package includes the following items:

♦ Invertig 301 AC/DC Power Source

♦ 26 Series Air-Cooled TIG Torch with Heavy Hitter Flex Head (350 amps)

♦Foot Pedal

♦ Flowmeter

♦ Gas Hose

♦ Ground Cable and Clamp Assembly

♦ Single Phase Plug



Please note that you can customize the length of your accessories, type of torch head and you can also swap the foot pedal for a hand control in the drop down boxes.  When you select the 25' option your torch, foot pedal and ground clamp will all be changed to the 25' length.



This package does not include a cart.
