Plasma Cutters

Your choice of torch, 10ft ground clamp, 220v to 110V adapter cord

Does Not Include:
Welding Cart and Air Dryer

MicroCut 45 DV HTP America

Product # MC45DVhtgroup
  • Regular priceList

  • Our Price:
  • $1,599.00

  • You Save: $383.75 !

Financing as low as


Apply Now!

MicroCut 45 DV HTP America:

The MicroCut 45 DV is the newest machine added to the HTP lineup. What is new about this machine? CNC capabilities come standard, Dual Voltage machine, lighter weight, and an LCD Display!

*Please select what torch you would like below. You can choose from a hand cutting torch or CNC machine torch below.*

We have thoroughly tested the MicroCut 45 DV on its precision and duty cycle. While running on 220V it will output a maximum 45 amps; on 110V it will output 25 amps.  This machine is not approved for use with a generator. Hand cutting or CNC cutting this machine is sure to meet your expectations. Maximum severance cutting capacity is 1 inch, maximum quality cutting is 3/4".

With the MicroCut 45 DV, the maximum rated CNC pierce capacity is 1/2"; the cut speed at 1/2" material thickness runs at 16 IPM. To use your MicroCut 45 DV on your plasma table, simply install your CNC machine torch, plug in your table, and switch the cutter into CNC mode. The MicroCut 45 DV DOES NOT include the 14-Pin Mating Connector (P/N 64672)


The MicroCut 45 DV packs powerful performance into a lightweight design. Thick or thin, the MicroCut 45 DV gets the job done! Backed by a 2-year warranty and a 30-day money back guarantee.

To get the best cutting capacity, fastest cutting speeds, and longest consumable life out of your CNC plasma cutting applications, we highly recommend using our HTP Max Dry desiccant air dryer system (P/N 25310-2). Dry air is a necessity when running a CNC with a torch height controller.

For torch consumables/parts, please visit the following page: MicroCut 45 DV Hand and Machine Torches and Parts.

If you would like to purchase a hand torch, in addition to the machine torch, please visit the following page: MicroCut 45 DV Hand Torch.

The MicroCut 45 DV HTP America Specifications:

 220V110 V
Input Voltage230V120V
Input Amperage45A30A
Cutting Current20 to 45 A
Infinitely Variable
20 to 25 A
Infinitely Variable
Open Circuit Voltage
Cutting Voltage230V
Maximum CNC Cutting Capacity½" @ 16 IPM
Quality Cutting Capacity¾" @ 6.5 IPM
Severance Cutting Capacity1" @ 4 IPM
Duty-Cycle (104 F)

50% @ 45A
60% @ 41 A

100% @ 32 A

40% @ 25 A

60% @ 27 A

100% @ 21 A

Weight29 Lbs.
Dimensions (Length x Width x Height)18-3/4" x 6-¾" x 12-½"
Cutting Torch Length20'
Ground Length10'
Input Power Cord Length9'
Plasma/Cooling Gas Pressure70 PSI
Plasma/Cooling Gas Volume3.5 CFM


  Owner’s Manual

The MicroCut 45 DV HTP America Accessory Packages:

The HTP Micro Cut is available in three packages:


Hand torch Package

The Hand torch package comes with the 20' hand torch, 10' ground clamp assembly and the 110/220 adapter cord.


Machine Torch Package

The Machine torch package comes with the 20' machine torch, 10' ground clamp assembly and the 110/220 adapter cord (machine comes with CNC board already installed)


Both Torches

This package comes with both the 20' hand torch and machine torch, 10' ground clamp assembly and the 110/220 adapter cord (machine comes with CNC board already installed)


CA Prop 65 - For Residents of California
Warning: Welding and cutting equipment, accessories, and fumes can expose you to chemicals, including Chromium (Hexavalent Compounds), Lead, and Nickel, which are known to the State of California to cause cancer and/or birth defects or other reproductive harm. For more information, please visit
Customer Reviews
5.0 Based on 1 Reviews
5 ★
4 ★
3 ★
2 ★
1 ★
Write a Review

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
Glen S.
United States United States

Great Plasma Machine

I am very satisfied with the Micro Cut 45 . Mostly use it with my plasma table. Travels easy when necessary,very light. I started out using the hand torch which I thought was fine. Peter Z. suggested that I try the machine torch, the cut is flawless. Good to have both. It is great for gouging as well. I've cut 12 gauge to 1/2" so far and the cut was clean and dross was easily removed. Thanks again
